PUSH SWITCH

SPECIFICATION:

RATING :
5A 125/250VAC (UL, CUL)
5A 250V~u 25T85 5E4 (ENEC)
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : -25~85℃
ELECTRICAL LIFE : 5,000 CYCLES

SPECIFICATION:

RATING : 0.7A 250VAC T85 1E5

INSULATION RESISTANCE : DC 500V 100MΩ OR MORE

CONTACT RESISTANCE : DC 2-4V 1A 100mΩ OR LESS

WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

AMBIENT TEMPERATURE : -10℃ TO 85℃

ELECTRICAL LIFE : 100,000 CYCLES

SPECIFICATION:

RATING : 0.3A 125VAC, 0.15A 250VAC T125 5E4 (ENEC)
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 100mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : 0~125℃
ELECTRICAL LIFE : 50,000 CYCLES

SPECIFICATION:

RATING : 2A 125VAC,1A 250VAC
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 100mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : 0~55℃
ELECTRICAL LIFE : 10,000 CYCLES

SPECIFICATION:

RATING : 0.2(0.2)A 250~ 25T125 5E4
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : -25~125℃
ELECTRICAL LIFE : 50,000 CYCLES

SPECIFICATION:

RATING :

16A 125/250VAC, 3/4HP 125~250VAC (UL,CUL)

12(8)A 250V~T55 (ENEC)

INSULATION RESISTANCE : DC 500V 100MΩ OR MORE

CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS

WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

AMBIENT TEMPERATURE : 0℃ TO 55℃

ELECTRICAL LIFE : 10,000 CYCLES

SPECIFICATION:

RATING :
10A 250VAC, TV-8 (UL, CUL)
8/128A 250V~ 10T85 (ENEC)
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : -10~85℃
ELECTRICAL LIFE : 10,000 CYCLES

SPECIFICATION:

RATING :
10A 125/250VAC (UL, CUL)
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : 0~55℃
ELECTRICAL LIFE : 6,000 CYCLES

SPECIFICATION:

RATING : 16A 125/250VAC (UL,CUL)
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : 0~65℃
ELECTRICAL LIFE : 6,000 CYCLES

SPECIFICATION:

RATING : 8A 125VAC , 4A 250VAC, 15mA/36VDC
CIRCUIT : ON OFF / (ON) - OFF
INSULATION RESISTANCE : DC 500V 100M OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 100m OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : -30℃ TO 70℃
Mounting hole size : Ø12/16/19/22mm
Degree of protection : IP65 / IP67
