ROCKER SWITCH

SPECIFICATION:

RATING :

12(4)A 250V~ T85, 8/128A 250V~ T85(UL,CUL,ENEC)
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : 0~85℃
ELECTRICAL LIFE : 10000 CYCLES

SPECIFICATION:

RATING :
6A 125VAC, 6A 250VAC (UL, CUL)
6(4)A 250V~ T85 (ENEC)
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : 0~85℃
ELECTRICAL LIFE : 10000 CYCLES

SPECIFICATION:

RATING :
16A 125VAC, 10A 250VAC,1/3HP 125/250VAC(UL, CUL)
16(4)A 250V~ T85,10/100A 250V~ T85 (ENEC)
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : 0~85℃
ELECTRICAL LIFE : 10000 CYCLES

SPECIFICATION:

RATING :
16A 125VAC, 16A 250VAC (UL, CUL)
16(4)A 250V~ T85 (ENEC)
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : 0~85℃
ELECTRICAL LIFE : 10000 CYCLES

SPECIFICATION:

RATING : 16A 125VAC, 16A 250VAC (UL, CUL)
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : 0~85℃
ELECTRICAL LIFE : 6000 CYCLES

SPECIFICATION:

RATING :
20(8)A 250V~ T85 (UL, CUL, ENEC)
10(6)A 250V~ T85 5E4 (UL,CUL,ENEC)
3/4HP 125/250VAC T85 (UL,CUL)
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : 0~85℃
ELECTRICAL LIFE : 10000 CYCLES

SPECIFICATION:

RATING :
20(12) 250V~ T100 (UL, CUL,ENEC)
10(4) 250V~ T100 5E4 (UL,CUL,ENEC)
10/100A 250V~ T100 (UL,CUL,ENEC)
INSULATION RESISTANCE : DC 500V 100MΩ OR MORE
CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS
WITHSTAND VOLTAGE : AC 1500V FOR 1 Min
AMBIENT TEMPERATURE : 0~100℃
ELECTRICAL LIFE : 10000 CYCLES
