• 601X Series TOGGLE SWITCH

    SPECIFICATION:



    RATING :

    16A 125VAC, 10A 277VAC (UL,CUL)

    16(6)A 250V~T125 (ENEC,CQC)

    INSULATION RESISTANCE : DC 500V 100MΩ OR MORE

    CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS

    WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

    OPERATIONS : SPST, SPDT

    Inquiry Info. More Information

  • 602X Series TOGGLE SWITCH

    SPECIFICATION:



    RATING :

    16A 125VAC, 10A 277VAC (UL,CUL)

    16(6)A 250V~T125 (ENEC,CQC)

    INSULATION RESISTANCE : DC 500V 100MΩ OR MORE

    CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS

    WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

    OPERATIONS : SPST, SPDT,DPDT

    Inquiry Info. More Information

  • 701X Series TOGGLE SWITCH

    SPECIFICATION:



    RATING :

    15A 125VAC, 10A 250VAC (UL,CUL)

    20A 125/250VAC (IN HOUSE TEST)

    INSULATION RESISTANCE : DC 500V 100MΩ OR MORE

    CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS

    WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

    Inquiry Info. More Information

  • 702X Series TOGGLE SWITCH

    SPECIFICATION:



    RATING :

    15A 125VAC, 10A 250VAC (UL,CUL)

    20A 125/250VAC (IN HOUSE TEST)

    INSULATION RESISTANCE : DC 500V 100MΩ OR MORE

    CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS

    WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

    Inquiry Info. More Information

  • 703X Series TOGGLE SWITCH

    SPECIFICATION:



    RATING :

    15A 125VAC, 10A 250VAC (IN HOUSE TEST)

    20A 125/250VAC (IN HOUSE TEST)

    INSULATION RESISTANCE : DC 500V 100MΩ OR MORE

    CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS

    WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

    OPERATIONS : 3PST, 3PDT

    Inquiry Info. More information

  • 7101 TOGGLE SWITCH

    SPECIFICATION:



    RATING :16A 125/250VAC (UL,CUL)

    INSULATION RESISTANCE : DC 500V 100MΩ OR MORE

    CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS

    WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

    Inquiry Info. More information

  • 801X Series Toggle Switch

    SPECIFICATION:



    RATING : 16A(6)A 250V~T55 (ENEC)

    INSULATION RESISTANCE : DC 500V 100MΩ OR MORE

    CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS

    WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

    ELECTRICAL LIFE : 10000 CYCLES

    Inquiry Info. More Information

  • 802X Series Toggle Switch

    SPECIFICATION:



    RATING : 16A(6)A 250V~T55 (ENEC)

    INSULATION RESISTANCE : DC 500V 100MΩ OR MORE

    CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS

    WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

    ELECTRICAL LIFE : 10000 CYCLES

    Inquiry Info. More Information

  • 901 SERIES TOGGLE SWITCH

    SPECIFICATION:



    RATING :
    20GP/RA 250V~ 25T125 (UL,CUL,ENEC)
    16(6)A 250V~ 40T125 (UL,CUL,ENEC)
    7A 72VDC 14A 36VDC 40T125 (UL,CUL,ENEC)

    INSULATION RESISTANCE : DC 500V 100MΩ OR MORE

    CONTACT RESISTANCE : DC 2-4V 1A 20mΩ OR LESS

    WITHSTAND VOLTAGE : AC 1500V FOR 1 Min

    AMBIENT TEMPERATURE: -40~125°C

    ELECTRICAL LIFE : 10,000 CYCLES


    Inquiry Info. More Information
